ACACIA
Like any Bodhi Van, the Acacia 144 floor plan was crafted with the intention to maintain the beauty and warmth of a home that is often lost in many “RV style” builds.
While the Acacia features our smallest and most affordable system, it is capable of meeting the majority of van lifers needs. Its 300ah battery system and 3 way charging system (dc to dc, 375w solar, shore power) are ideal for one to two week trips and some full time living. This system is 100% in the Victron ecosystem for ease of use and unmatched support and can be easily upgraded to a 400ah battery system.
The water system comes with a 20g fresh water tank and an 11g gray water tank located on the passenger side kitchenette and a 2.5 gallon hot water heater.
Stay cozy in cold weather with the ultra efficient Espar Airtronic heating system that integrates with your vehicle's fuel system for ease of use. For cooling down this system features a maxxair fan for warmer nights. If you are interested in an A/C system for your van, please check out our Juniper Layout.
Build Out Starting Price: $84,955
2022/23 Van Availability: Contact us for options.
VAN SPECS
MAKE + MODEL: NEW MERCEDES-BENZ SPRINTER
WHEELBASE: 144
HEIGHT: HIGH ROOF
DRIVE: 4x4
DETAILS
KITCHEN
2.3 Cu.Ft. Refrigerator W/ Freezer, Black Stainless Sink and Faucet
Bamboo Ply Countertops W/ Countertop Extension
Drawer Storage Above Fridge
Portable Single Burner Induction Cooktop
Sleeping
Lofted Queen Sized Bed With Flarespace Flares For Sideways Sleeping
Available at Two Heights For Different Garage Capacities
SEATING
Bench W/ Storage and Concealed OGO Composting Toilet
Custom Sunbrella Upholstered Cushions
Lagun Swivel Table
Swivel Seats Available for Passenger and Driver Seats
INTERIOR
Havlock Wool Insulation
Lap & Slat Style Walls and Ceiling
Custom Hand-Built Plycore Cabinetry W/ Leather Pulls
Marine Grade Vinyl Plank Flooring
Premium Concealed LED Floor and Ceiling Lighting
Sound Dampening Throughout
Divider Wall Storage Nook and Shelves
WINDOWS
Passenger Side Sliding Vent Window
(2) Rear Cargo Door Windows
(2) Sliding Flare Windows
Van Essentials Magnetic Window Covers
SYSTEM + GEAR
ELECTRICAL
Up to 640Ah Lithium Batteries
12/3000 Victron Inverter
3-Way Charging
Touchscreen Controls
(1) 110V USB Combo Outlets + (2) 12V GFCI Outlets + (1) 12V Outlet
WATER
20 Gallon Freshwater Tank
11 Gallon Greywater Tank
Water Heater
Hospital Grade Water Filter
Rear Outdoor Shower
HEATING AND COOLING
Rixen Hydronic System or Espar Diesel Heater
Up to 2 Maxxair Roof Fans and/or 12v AC Unit
Gear
Owl Vans Ladder + Tire Carrier
Optional Roof Rack, Runners, and Cargo Carriers
